Thermal Conductivity: 3.0 W/m·K. This indicates the efficiency of the pad in conducting heat.
Material: Made of silicone, which offers flexibility, durability, and good thermal performance.
Thickness: Available in various thicknesses to suit different applications and component heights.
Adhesion: Some pads come with adhesive properties for easy application, while others may require mechanical attachment.
Dielectric Strength: Silicone pads often provide electrical insulation, which is important for preventing short circuits.
Compliancy: Silicone pads are soft and can conform to the surface irregularities of components, enhancing contact and thermal transfer.
Improved Thermal Performance: Enhances heat dissipation, reducing the risk of overheating and thermal throttling.
Easy to Apply: Can be easily cut to size and applied without the need for curing or special handling.
Electrical Insulation: Provides electrical isolation, protecting sensitive components.
Durability: Resistant to environmental factors like moisture and temperature variations.
| Testing Item | Testing Value | Testing Method |
| Thickness(MM) | 0.3-15MM or Customized | ASTM D374 |
| Components | Silicone Rubber &Ceramics | -- |
| Colour | Blue or Customized | Visual |
| Hardness (Shore C) | 20-50 | ASTM D2240 |
| Density(G/M3) | 3.0±0.1 | ASTM D792 |
| Tensile Strength(KN/M) | 0.2 | ASTM D412 |
| Extensibility(%) | 60 | ASTM D374 |
| Working Temperature(℃) | -40~200 | EN344 |
| Breakdown Voltage(KV) | >9 | ASTM D149 |
| Volume Resistivity(Ω·CM) | 1.5×1011 | ASTM D257 |
| Dielectric Constant(@1MHz) | 7..2 | ASTM D150 |
| Weight Loss ratio (%) | <2 | @200℃240H |
| Flaming Rating | V-0 | UL-94 |
| Thermal Conductivity(W/M.K) | 3.0 | ASTM D5470 |
