High Thermal Conductivity: With a thermal conductivity rating of 1.0W/M.K, this grease provides superior heat dissipation.
Stable Performance: Maintains consistent performance across a wide temperature range, ensuring reliable operation in varying conditions.
Non-Corrosive: Formulated to be non-corrosive, protecting sensitive electronic components from damage.
Easy Application: The grease's smooth consistency allows for easy application, ensuring a uniform layer and efficient thermal transfer.
Preparation: Ensure both the component and heat sink surfaces are clean and free of any old thermal grease, dust, or debris.
Application: Apply a small amount of silicone thermal grease to the center of the component.
Spreading: Using a spatula or the component itself, spread the grease evenly to form a thin, uniform layer.
Testing Item | Unit | Testing Method | Testing Value |
Colour | - | Visual | White or customized |
Thermal Resistance | ℃-in2/W | ASTM D5470 | ≤0.25 |
Component Ratio | - | ASTMD1475 | >2.0 |
Evaporation | % | Fed.Std.791 | <0.001 |
Oil Precipitation | % | Fed.Std.791 | <0.05 |
Dielectric Constant | - | ASTM D150 | >5 |
Viscosity | ( mPa.s@25℃) | DHR-2 | (100~300)*104 |
Cone Penetration | 1/10 MM | GB/T-269 | 410±10 |
Working Temperature | ℃ | - | -40~200℃ |
Flaming Rating | - | UL 94 | V0 |
Weight loss | % | <1 | @200°200H |
Density | g/cc | 2.2(±0.3) | ASTM D792 |
Thermal Conductivity | W/M.K | ASTM D5470 | 1.0 |
